C-PRO KILO HARDWARE MANUAL
Page 20
Current measurement sensitivity
Type
Voltage measurement range
Voltage measurement accuracy
Voltage measurement sensitivity 0.01 mA; Ri = 200 Ohm
Ratiometric
0
÷
5V
±50mV
10mV
Fan output Number 1
Type EVDFAN1 phase chop module
pulses
UART1 TTL Number 1
for RS-485 serial port Type UART
(Modbus) Physical layer TTL signal level
Maximum baud rate 19200 bit/s
Connector AMP micro-match 6 pin
Please note: The same serial connector
is used for the parameter key and the
interface used to program the
microcontroller flash memory
Serial output for remote Number 1
I/O expansion card Type EVCO live serial port
and remote keypad Physical layer 12 VDC, GND, DATA
Baud rate 19200 bit/s
Connector Phoenix detachable
Analogue output Number 1+1
Voltage + Voltage Connector Phoenix detachable
Voltage + Current or
Current + Current only
on request Power supply Internally optoisolated
Type Current
Current range 4 - 20 mA
Current output accuracy ±1 mA
Current output sensitivity 0.05 mA
Current output load 47 - 300
Ω
Adjustment time 1 s
Type Voltage
Voltage range 0
÷
10 V
Voltage output accuracy ±200 mV (no load)
Voltage output sensitivity 10 mV
Output impedance 100
Ω
Adjustment time 1 s
Number 1
type CAN V2.0B no optoinsulated
Physical layer 2 wires + common wire
(ISO 11898)
Baud rate (max. length = 1000 m) 20K
Baud rate (max. length = 500 m) 50K
Baud rate (max. length = 250 m) 125K
Baud rate (max. length = 50 m) 500K
CAN communication
Bus
Connector Disconnectable screw terminals
