C-PRO KILO HARDWARE MANUAL
Page 26
5
C-PRO EXP KILO I/O expansion units
The C-PRO EXP KILO I/O expansion units allow expansion of the controller I/O capacity. There are two types
of expansion units, closed case versions in 10 DIN module cases and open case versions mounted on 10 DIN
module bases.
It is also possible to use C-PRO EXP MICRO range I/O expansion units.
The following table illustrates the main features of the C-PRO KILO:
Version
Power
supply
Analogue
inputs
(1)
Digital
inputs
Analogue
output 1
(2)
Analogue
outputs
2 and 3
(3)
Digital
outputs
(electromech
anical relays)
Closed case
24 VAC/
20 … 60
VDC
5
7
Yes
Available on
request
7
Open case
24 VAC/
20 … 60
VDC
5
7
Yes
No
7
(1)
3 for NTC probes and 2 for NTC probes/0-5 V ratiometric transducers (on request)/0-20 mA
transducers/4-20 mA transducers
(2)
for controlling the EVDFAN1 phase chopping module (optoisolated output)
(3)
0-10 V or 4-20 mA (optoisolated outputs; all three combinations are possible).
