EVCO S.p.A. c-pro 3 NODE kilo | Hardware manual ver. 1.0 | Code 114CP3NKE104
page 6 of 44
1.2 Summary table of available models, their main characteristics and purchase
codes
The following table contains a description of the available models.
Available models EPK4BHX EPK4BHR EPK4LHX EPK4LHR EPK4DHX EPK4DHR
The following table shows the main characteristics of the devices.
Version EPK4BHX EPK4BHR EPK4LHX EPK4LHR EPK4DHX EPK4DHR
blind • •
built-in LED (custom 4+4 digit
display)
• •
built-in LCD (128 x 64 pixel single
colour LCD graphic display)
• •
Dimensions EPK4BHX EPK4BHR EPK4LHX EPK4LHR EPK4DHX EPK4DHR
DIN modules 8 8 8 8 8 8
Connections EPK4BHX EPK4BHR EPK4LHX EPK4LHR EPK4DHX EPK4DHR
screw-in removable terminal boards • • • • • •
Power supply EPK4BHX EPK4BHR EPK4LHX EPK4LHR EPK4DHX EPK4DHR
24 VAC/DC not insulated • • • • • •
Analog inputs EPK4BHX EPK4BHR EPK4LHX EPK4LHR EPK4DHX EPK4DHR
PTC/NTC/Pt 1000 3 3 3 3 3 3
PTC/NTC/Pt 1000/0-20 mA/4-20
mA/0-5 V ratiometric/0-10 V
3 3 3 3 3 3
Digital inputs (for NA/NC
contact)
EPK4BHX EPK4BHR EPK4LHX EPK4LHR EPK4DHX EPK4DHR
opto-isolated 24VAC/DC 50/60 Hz
contacts
3 3 3 3 3 3
opto-isolated 24 VAC/DC 50/60 Hz/
2 KHz contacts
2 2 2 2 2 2
Analog outputs EPK4BHX EPK4BHR EPK4LHX EPK4LHR EPK4DHX EPK4DHR
PWM/0-10 V 2 2 2 2 2 2
