EVCO S.p.A. c-pro 3 NODE kilo | Hardware manual ver. 1.0 | Code 114CP3NKE104
page 23 of 44
6.5 List of configuration parameters
6.5.1
Configuration parameters of the "Info" menu
The following table shows the meaning of the configuration parameters of the "Info" menu.
PARAM. MIN. MAX. M. U. DEF. DESCRIPTION
PROJ parameter available in read only mode
Information on the application project (project, version and
revision)
FW parameter available in read only mode
Information on the firmware (code, version, revision and sub-
revision)
HW parameter available in read only mode
Information on the hardware (version, revision, generic (G) or
special (S))
SW parameter available in read only mode
Information on the UNI-PRO 3 development environment
(version and revision).
SN parameter available in read only mode
Information on the serial number and the results of the
production tests
MASK parameter available in read only mode
Information on the mask (depends on the manufacturer's coding
system)
DATE parameter available in read only mode date and time of the latest compilation of the application project.
6.5.2
Configuration parameters of the "Parameters" menu
The following table shows the meaning of the configuration parameters of the "Parameters" menu.
PARAM. MIN. MAX. M. U. DEF. DESCRIPTION
AI1 - - - - - - - - - NTC
type of probe analog port 1
PTC = PTC probe
NTC = NTC probe
0-20mA = Transducer 0-20 mA
4-20mA = Transducer 4-20 mA
0-5V = Transducer 0-5 V ratiometric
0-10V = Transducer 0-10 V
PT1000 = Pt 1000 probe
NTCK2 = Type 2 NTC probe
NTCK3 = Type 3 NTC probe
RESIST = electric resistance reading
