EVCO S.p.A. c-pro 3 NODE kilo | Hardware manual ver. 1.0 | Code 114CP3NKE104
page 36 of 44
8 TECHNICAL DATA
8.1 Technical data
Purpose of the command device: operating command device.
Construction of the command
device:
built-in electronic device.
Container: grey self-extinguishing.
Heat and fire protection class: D.
Dimensions:
142.0 x 128.0 x 60.0 mm (5.590 x 5.039 x 2.362 in; L x H x D); 8 DIN modules
The dimensions refer to the device with all the screw-in removable terminal boards in place.
Method of mounting the
command device:
on a DIN 35.0 x 7.5 mm (1.377 x 0.295 in) or 35.0 x 15.0 mm (1.377 x 0.590 in), track in
a control panel.
Protection grade:
- IP20 overall
- IP40 for the front.
Connections
- screw in removable terminal board, male only 3,5 mm pitch (0,137 in) for wires
up to 1,5 mm² (0,0028 in²): power supply, analog inputs, digital inputs, analog
outputs and ports RS-485 MODBUS slave, RS-485 MODBUS master/slave and
CAN CANBUS
- screw in removable terminal board, male only 5 mm pitch (0,196 in) for wires
up to 2,5 mm² (0,0038 in²): digital outputs
- type A USB connector: USB port
- RJ45 F phone connector: MODBUS TCP Ethernet port.
