EVCO S.p.A. c-pro 3 NODE kilo | Hardware manual ver. 1.0 | Code 114CP3NKE104
page 19 of 44
6 CONFIGURATION
6.1 Configuration of abuilt-in LCD programmable controller
To access the procedure, proceed as follows:
1. Check that the power is on.
2. Keep the UP and DOWN keys pressed for 2 s: the following menu (hereinafter, the "Main menu") shall appear on the
display,
Info
English
Parameters
Networks
Backup/Restore
Diagnostic
Debug
To access the sub-menus, proceed as follows:
3. Press and release the UP or DOWN key to select the relevant sub-menu.
4. Press and release the ENTER key.
To access the "Parameters", "Networks", "Password" and "Backup/Restore" sub-menus, proceed as follows:
5. Starting from point 2, press and release the UP or DOWN key to select the relevant sub-menu.
6. Press and release the ENTER key.
7. Press and release the ENTER key again to set the password
8. Press and release the DOWN key repeatedly to set "-19".
9. Press and release the ENTER key again.
To adjust a parameter, proceed as follows:
10. From point 9, press and release the UP or DOWN key to select the parameter (some parameters are included in sub-
menus; press and release the ENTER key to access them).
11. Press and release the ENTER key.
12. Press and release the UP or DOWN key to change the value.
13. Press and release the ENTER key to confirm the set value
14. Press and release the ESC key repeatedly to go back to the "Main menu".
To change the language of the application software, proceed as follows:
15. From point 2, press and release the UP or DOWN key to select the "Language" item (the default setting is "English").
16. Press and release the ENTER key.
17. Press and release the UP or DOWN key to change the language.
18. Press and release the ENTER key to confirm the set value
To change the current date and time, proceed as follows:
19. Starting from point 2, press and release the UP or DOWN key to select the "Current date and time" item.
20. Press and release the ENTER key.
21. Press and release the UP or DOWN key to change the value.
22. Press and release the ENTER or RIGHT keys to confirm the value and change the following field (press and release the LEFT
or RIGHT keys to move between fields)
23. Repeat points 21 and 22.
To copy the controller parameters to a USB peripheral device, proceed as follows:
24. Check that the power is on.
25. Connect the peripheral device to the controller.
26. Access the "Backup/Restore" sub-menu, then choose "Parameters key" (Choose "Backup Memory" for the backup memory)
27. Press and release the UP or DOWN key to select "Application par" to copy the parameters of the application software, or
"Hardware config" to copy the configuration parameters.
28. Press and release the UP or DOWN key to select "Save on the key"
