EVCO S.p.A. c-pro 3 NODE kilo | Hardware manual ver. 1.0 | Code 114CP3NKE104
page 33 of 44
KEY PAR parameter available in read-only mode
result of the upload or download of the application software
parameters or of a configuration through USB drive.
OK = procedure completed successfully
ERR = procedure not completed successfully
6.5.10
Configuration parameters of the "Debug" menu
The following table shows the meaning of the configuration parameters of the "Debug" menu.
PARAM. MIN. MAX. M. U. DEF. DESCRIPTION
Main run
time
parameter available in read-only mode application software main cycle time (in ms)
max main
time
parameter available in read-only mode application software maximum main cycle time (in ms)
free stack
main
parameter available in read-only mode minimum free stack main (in byte)
100ms run
time
parameter available in read-only mode application software run time timed at 100 ms
100 ms max
time
parameter available in read-only mode application software maximum run time timed at 100 ms
free stack
100 ms
parameter available in read-only mode
application software free stack of the interrupt cycle at 100 ms (in
byte)
5V PROBE parameter available in read-only mode measurement of voltage supply of the ratiometric transducers
24V PROBE parameter available in read-only mode
measurement of the supply voltage of 0-20 mA, 4-20 mA and 0-
10 V transducers
24V parameter available in read-only mode measurement of the supply voltage coming from the upper board
Notes:
(1) to display the parameter, press the RIGHT key
(2) to display the parameter, press the RIGHT key; this parameter is not available in the built-in LED and blind versions.
