Al Err Time
0
240
s
2
analog ports time-out (if no communication with an analog port
is detected after this span of time, the controller notifies an
analog input error)
AO impulse
1
50
ms/10
20
duration of the cut phase impulse
AO1
- - -
- - -
- - -
0-10V
type of signal analog port 1
FAN
=
FAN (for cut phase module)
0-10V
=
0-10 V
PWM
=
PWM (Pulse With Modulation)
freq
10
2000
Hz
1000
frequency of the analog port 1 PWM-type signal
delay ph.
0
50
ms/10
0
displacement of the phase-cutting impulse from analog port 1
AO2
- - -
- - -
- - -
0-10V
type of signal analog port 2
FAN
=
FAN (for phase-cutting module)
0-10V
=
0-10 V
PWM
=
PWM (Pulse With Modulation)
freq
10
2000
Hz
1000
frequency of the analog port 2 PWM-type signal
delay ph.
0
50
ms/10
0
displacement of the phase-cutting impulse from analog port 2
AO3
- - -
- - -
- - -
0-10V
type of signal analog port 3
0-20mA
=
0-20 mA
4-20mA
=
4-20 mA
0-10V
=
0-10 V
I/O Timeout
(1)
1 240 s
60
CANBUS communication time-out to check the remote I/O values
(after this span of time has elapsed with no CANBUS
communication, the controller I/O is disabled)
AI1 filter
OFF
ON
- - -
ON
analog input 1 filter coefficient
AI2 filter
OFF
ON
- - -
ON
analog input 2 filter coefficient
AI3 filter
OFF
ON
- - -
ON
analog input 3 filter coefficient
AI4 filter
OFF
ON
- - -
ON
analog input 4 filter coefficient
AI5 filter
OFF
ON
- - -
ON
analog input 5 filter coefficient
AI6 filter
OFF
ON
- - -
ON
analog input 6 filter coefficient
DI1 filter
OFF
ON
- - -
ON
digital input 1 filter coefficient
DI2 filter
OFF
ON
- - -
ON
digital input 2 filter coefficient
