EVCO S.p.A. c-pro 3 NODE kilo | Hardware manual ver. 1.0 | Code 114CP3NKE104
page 32 of 44
- - - - - - - - - ON
enabling of the level 4 access password
OFF = no password needs to be set to access level 4
ON = it is necessary to set a password to access level 4
Level 5:
-32768 32768 - - - 0 value of the level 5 access password
- - - - - - - - - ON
enabling of the level 5 access password
OFF = no password needs to be set to access level 5
ON = it is necessary to set a password to access level 5
Timeout 0 240 s 240
timeout of access passwords (after this time has elapsed from the
latest keypad operation, it is necessary to set a new password to
access the relevant level, if so required).
6.5.9
Configuration parameters of the "Diagnostics" menu
The following table shows the meaning of the configuration parameters of the "Diagnostics" menu.
PARAM. MIN. MAX. M. U. DEF. DESCRIPTION
Memory parameter available in read-only mode
status of non-volatile memory
OK = no error
ERR = error
RTC parameter available in read-only mode
clock status
OK = no error
ERR = error
LOW = data loss
DISAB = disabled
STACK parameter available in read-only mode
stack status
OK = no error
ERR = error (overflow)
5V RATIO parameter available in read-only mode
status of the voltage supply of the ratiometric transducers
OK = no error
ERR = error (voltage out of range)
24V
SENSOR
parameter available in read-only mode
status of the supply voltage of 0-20 mA, 4-20 mA and 0-10 V
transducers
OK = no error
ERR = error (voltage out of range)
MATH parameter available in read-only mode
math status
OK = no error
ERR = error (overflow, under flow, division by zero or
NaN)
