EVCO S.p.A. c-pro 3 NODE kilo+ | Hardware manual ver. 1.0 | Code 114CP3NKPE104
page 7 of 55
PWM/0-10 V 2 2 2 2 2 2
0-20 mA/4-20 mA/0-10 V 2 2 2 2 2 2
Digital outputs
(electromechanical relays; A res.
@ 250 VAC)
EPK4BHQ EPK4BHT EPK4LHQ EPK4LHT EPK4DHQ EPK4DHT
3 A SPST 9 5 9 5 9 5
3 A SPDT 2 2 2 2 2 2
Digital outputs (controls for
solid state relays)
EPK4BHQ EPK4BHT EPK4LHQ EPK4LHT EPK4DHQ EPK4DHT
24 VAC/DC, 600 mA max 4 4 4
Communication ports EPK4BHQ EPK4BHT EPK4LHQ EPK4LHT EPK4DHQ EPK4DHT
RS-485 MODBUS slave 1 1 1 1 1 1
RS-485 MODBUS master/slave 1 1 1 1 1 1
CAN CANBUS 1 1 1 1 1 1
USB 1 1 1 1 1 1
Ethernet MODBUS TCP, Web Server 1 1 1 1 1 1
Other characteristics: EPK4BHX EPK4BHR EPK4LHX EPK4LHR EPK4DHX EPK4DHR
clock • • • • • •
For additional information, please read chapter 8 “
