29. Press and release the ENTER key: the parameters shall be copied from the controller into the peripheral device (the process
usually requires a few seconds; if an error should be present, the System alarm LED (see paragraph 5.2 LED warning
lights) shall light up and an Err. value shall be input in the Key Par (in the "Diagnostic" sub-menu) parameter.
30. Disconnect the peripheral device
To copy the USB peripheral device parameters to the controller, proceed as follows:
31. Check that the power is on.
32. Connect the peripheral device to the controller.
33. Access the "Backup/Restore" sub-menu, then choose "Parameters key" (Choose "Backup Memory" for the backup memory)
34. Press and release the UP or DOWN key to select "Restore from the key".
35. Press and release the ENTER key: the parameters shall be copied from the peripheral device into the controller (the process
usually requires a few seconds; if an error should be present, the System alarm LED (see paragraph 5.2 LED warning
lights) shall light up and an Err. value shall be input in the Key Par (in the "Diagnostic" sub-menu) parameter.
36. Disconnect the peripheral device
Copying the peripheral device parameters tp the controller is allowed provided that the controllers firmware coincides.
To exit the procedure, proceed as follows:
37. Press and release the ESC key repeatedly; any changes shall not be saved.
Disconnect the power supply after changing the configuration.
6.2 Configuration of a blind programmable controller
The following procedures show an example of how to configure a blind programmable controller through a built-in programmable
controller (in the example, c-pro 3 NODE kilo) and its user interface.
Proceed as follows:
1. Disconnect the controllers power supply
2. Connect the blind controller to the built-in controlled through the CAN CANBUS port; see chapter 4 “
