EVCO S.p.A.
c-pro 3 NODE kilo+ | Hardware manual ver. 1.0 | Code 114CP3NKPE104
page 31 of 55
ELECTRIC
CONNECTION
”.
3.
Connect the power supply of the controller and the expansion
4.
Keep the UP and DOWN keys pressed for 2 s: the following menu shall appear on the display,
Info
English
Parameters
Networks
Backup/Restore
Diagnostic
Debug
5.
Press and release the UP or DOWN key to select "Networks".
6.
Press and release the ENTER key.
7.
Press and release the ENTER key again to set the password
8.
Press and release the DOWN key repeatedly to set "-19".
9.
Press and release the ENTER key again.
10.
Press and release the UP or DOWN key to select "CAN Bus".
11.
Press and release the ENTER key again.
12.
Set the "NetworkNode" parameter using the UP or DOWN keys to select the parameter and the ENTER key to change and
confirm the relevant value.
The default setting of the CAN node of an I/O expansion is 2 (operate on the controller to set the "NetworkNode" parameter to [ 2 ] 2).
13.
Press and release the UP or DOWN key to select ">".
14.
Press and release the ENTER key again: the "Main menu" of the expansion shall be shown on the display.
15.
Proceed as shown in paragraph 6.1 “Configuration of abuilt-in LCD programmable controller”.
6.4
Configuration of a programmable controller through a remote user interface
The following procedures show an example of how to configure a programmable controller through a remote user interface (in the
example, Vgraph) and its user interface.
Proceed as follows:
1.
Disconnect the power supply of the controller and the interface.
2.
Connect
the
controller
to
the
interface
through
the
CAN
CANBUS
port;
see
chapter
4
“
