c-pro 3 NODE kilo+ | Hardware manual ver. 1.0 | Code 114CP3NKPE104
page 32 of 55
ELECTRIC
CONNECTION
”.
3.
Keep the ESC and RIGHT keys pressed for 2 sec.
4.
Connect the power supply of the controller and the interface.
5.
When the interface display shows the following menu, release the ESC and RIGHT keys.
Vgraph
Parameters
Contrast
CAN Network
Modbus
Info
Debug
6.
Press and release the UP or DOWN key to select "CAN Network".
7.
Press and release the ENTER key.
8.
Press and release the ENTER key again to set the password
9.
Press and release the DOWN key repeatedly to set "-19".
10.
Press and release the ENTER key again.
11.
Set the "NW Node" parameter using the UP or DOWN keys to select the parameter and the ENTER key to change and
confirm the relevant value.
The default address of the CAN node of a programmable controller is 1 (operate on the remote user interface to set the "NW Node"
parameter to [ 1 ] 1) and the address if the CAN node of an I/O expansion is 2 (operate on the remote user interface to set the "NW
Node" parameter to [ 2 ] 2)
12.
Disconnect the user interface power supply
13.
Connect the user interface power supply
14.
Keep the LEFT and ENTER keys pressed for 2 s: the following menu shall appear on the display,
Network Status
Loc
99
OK
> >
1
1
OK
> >
2
2
OK
> >
3
0
-
> >
4
0
-
> >
5
0
-
> >
15.
Press and release the UP or DOWN key to select the device
16.
Press and release the ENTER key: the "Main menu" of the device shall be shown on the display.
17.
Proceed as shown in paragraph 6.1 “Configuration of abuilt-in LCD programmable controller”.
