1.2 Summary table of available models, their main characteristics and purchase
codes
The following table contains a description of the available models.
Available models EPK4BHQ EPK4BHT EPK4LHQ EPK4LHT EPK4DHQ EPK4DHT
The following table shows the main characteristics of the devices.
Version EPK4BHQ EPK4BHT EPK4LHQ EPK4LHT EPK4DHQ EPK4DHT
blind • •
built-in LED (custom 4+4 digit
display)
• •
built-in LCD (128 x 64 pixel single
colour LCD graphic display)
• •
Dimensions EPK4BHQ EPK4BHT EPK4LHQ EPK4LHT EPK4DHQ EPK4DHT
DIN modules 8 8 8 8 8 8
Connections EPK4BHQ EPK4BHT EPK4LHQ EPK4LHT EPK4DHQ EPK4DHT
screw-in removable terminal boards • • • • • •
Power supply EPK4BHQ EPK4BHT EPK4LHQ EPK4LHT EPK4DHQ EPK4DHT
24 VAC/DC not insulated • • • • • •
Analog inputs EPK4BHQ EPK4BHT EPK4LHQ EPK4LHT EPK4DHQ EPK4DHT
PTC/NTC/Pt 1000 4 4 4 4 4 4
PTC/NTC/Pt 1000/0-20 mA/4-20
mA/0-5 V ratiometric/0-10 V
6 6 6 6 6 6
Digital inputs (for NA/NC
contact)
EPK4BHQ EPK4BHT EPK4LHQ EPK4LHT EPK4DHQ EPK4DHT
opto-isolated 24VAC/DC 50/60 Hz
contacts
11 11 11 11 11 11
opto-isolated 24 VAC/DC 50/60 Hz/
2 KHz contacts
2 2 2 2 2 2
Analog outputs EPK4BHQ EPK4BHT EPK4LHQ EPK4LHT EPK4DHQ EPK4DHT
0-10 V 2 2 2 2 2 2
