7. PROGRAMMING PROCEDURES
EMI-31059
Menu No. 13
Menu No. 13
• Switching In-Llne/Off-Llne
When the SL-6600 is used as a satellite in an in-line system, the “ID No.” and “Transmission delay
time” can be set by the following procedure.
Select programming
menu #13.
Select the in-line
system.
The ID # can be set
when initial set #7-5
is “0”.
The transmission
delay time can be
set when In-line
system is selected
for TMCC-3.
1
PROG.
ON-LINE/LOCAL
P
13
OFF-LINE
P13 DF
I—
o
OFF-Line —► TDLC
------TMCC-3
FDLC -1
i
---- 1
ex.)
ENTER
ENTER
TMCC-3 (TR-TIME)
P13 b3 th
(Range; 1 -9)
TMCC-3 (TR-TIME)
PROG.
(Select another
programming menu.)
TMCC-3 (I.D.#)
P13 b3
Id 0
r
TMCC-3 (I.D.#)
5
0
(Range: 0~255)
P13 b3 Id 50
P13 t3 th 3
TMCC-3 (I.D.#)
P13 b3
Id 50
ON-LINE/LOCAL
P
13
NOTE: • At present, the SL-6600 cannot be used with the in-line system of TDLC.
•
The TMCC-3 baud rate is fixed to 4800 BPS.
•
To use the SL-6600 in off-line, select OFF-LINE with the key then press the ENTER
key.
Table 6: Transmission Delay Time Table
TR-TIme (ms)
TR-TIme (ms)
1
20 ~ 39
6
120 - 139
2
40 ~ 59
7
140 ~ 159
3
60 - 79
8
160 - 179
4
80 ~ 99
9
180 ~ 199
5
too ~ 119
7-44
