13. CLEANING THE PRINT HEAD

EM 1-31059

13. CLEANING THE PRINT HEAD

If the print head is dirty, clear printing will not be produced. It is recommended to clean the head with

thermal head cleaner everyday before starting operation using the following procedure:

1. Remove the printer cover and label cassette.

Then push the head-up lever in the direction

indicated by the arrow.

Head-up Lever

Wipe off the dirt on the blackened portion in
the diagram to the right with the thermal

head cleaner.

Then set the label cassette, and push down
the print head.

NOTE: Be careful not to damage the print head

when cleaning.

If any paste of the label applies on the label
cutter or printer cover, wipe off the paste

with alcohol.

Head

Thermal Head Cleaner

After removal of the Label Cutter, attach it in the following procedure.

Install the Label Cassette, which label is not loaded into, on the Scale.

2. Install the Label Cutter aligning the Cutter Notches with the Screw Holes.

3. Secure the Cutter with the White Screws where the bottom of the cutter is 0.3 ~1 mm

above from the Peel-off Plate.

Label Cutter

NOTE: In case the Cutter scratches a Label while printing, enlarge the clearance between the

Cutter and the Peel-off Plate.

1 3 - 1
