normal 12 keys that are found on your telephone the
transceiver also provides 4 additional keys, A, B, C and
D. These keys are required by some repeater systems for
various control operator of your repeater to determine
if their use is required. A chart is provided that lists the
various
tone
frequencies
that
are
generated
by
the
keypad. (Fig. 1)
To activate the keypad:
1. Press and hold the PTT switch.
2. Press the keys just like you would dial you telephone
at home.
Fig. 1
Fig. 2
Note
Some repeaters will require the use of a special key
sequence
to
activate
the
autopatch
function.
You
should
check
with
your
control
operator
for
this
sequence.
\Column
Row
1209
1336
1477
1633
697
1
2
3
A
770
4
5
6
B
852
7
8
9
C
941
*
0
-
D
1
697Hz
2
770Hz
3
852Hz
A
4
941Hz
5
1209Hz
6
1336Hz
B
7
1477Hz
8
1633Hz
9
C
*
0
#
D
Note
If one of the keys is pressed after the F key has been
pressed
during
transmission,
a
single
tone
will
be
heard. (Fig. 2)
