ALTANA Haze-Gloss Manual - Manual (Page 27)

- Mirror Mode:
0 = off
1 = on
- Custom. Calibration:
0 = off
1 = on
- Compensation:
0 = off
1 = on
- Selected Language:
0 = German
1 = English
2 = French
3 = Italian
4 = Spanish
Operating the haze-gloss via PC
(identical with function keys)
All keys on the unit are blocked except
for the operating switch
(1 byte INTEGER)
Byte
0 haze key
1 20 ° key
2 60 ° key
3 85 ° key
5 20 ° + 60° key
6 auto-range key
7 60 ° + 85° key
9 sample/statistic key
10 results key
11 set up key
14 delete key
15 operate key
(or operating switch):
The readings of the last measurement
are transferred to the PC (2 readings of
2 bytes each INTEGER multipied by 10,
LSB, MSB). Using a single angle
geometry, the second value is set to
zero.
‘P‘ Switch off ONLINE-operation,
haze-gloss keys are released
‘Q‘ Transfer of statistical values of the
required geometry to the computer
Computer code (1 byte INTEGER)
for the selected geometry:
0 20 ° values, single angle geometry
1 60 ° values, single angle geometry
2 85 ° values, single angle geometry
3 20 ° values, dual angle geom. (20 & 60°)
4 60 ° values, dual angle geom. (20 & 60°)
5 60 ° values, dual angle geom. (60 & 85°)
6 85 ° values, dual angle geom. (60 & 85°)
7 haze values
8 20 ° values in haze mode
haze-gloss code/characters
4 byte index (number of values)
2 byte each INTEGER
(multiplied by 10)
reflectometer values
- Mirror Mode:
0 = off
1 = on
- Custom. Calibration:
0 = off
1 = on
- Compensation:
0 = off
1 = on
- Selected Language:
0 = German
1 = English
2 = French
3 = Italian
4 = Spanish
Operating the haze-gloss via PC
(identical with function keys)
All keys on the unit are blocked except
for the operating switch
(1 byte INTEGER)
Byte
0 haze key
1 20 ° key
2 60 ° key
3 85 ° key
5 20 ° + 60° key
6 auto-range key
7 60 ° + 85° key
9 sample/statistic key
10 results key
11 set up key
14 delete key
15 operate key
(or operating switch):
The readings of the last measurement
are transferred to the PC (2 readings of
2 bytes each INTEGER multipied by 10,
LSB, MSB). Using a single angle
geometry, the second value is set to
zero.
‘P‘ Switch off ONLINE-operation,
haze-gloss keys are released
‘Q‘ Transfer of statistical values of the
required geometry to the computer
Computer code (1 byte INTEGER)
for the selected geometry:
0 20 ° values, single angle geometry
1 60 ° values, single angle geometry
2 85 ° values, single angle geometry
3 20 ° values, dual angle geom. (20 & 60°)
4 60 ° values, dual angle geom. (20 & 60°)
5 60 ° values, dual angle geom. (60 & 85°)
6 85 ° values, dual angle geom. (60 & 85°)
7 haze values
8 20 ° values in haze mode
haze-gloss code/characters
4 byte index (number of values)
2 byte each INTEGER
(multiplied by 10)
reflectometer values
