F7…HD Butterfl y Valves 2”–24” Ductile Iron Lug Body
Resilient Seat, 304 Stainless Disc
Technical Data
Service
chilled, hot water, 60% glycol
Flow characteristic
modifi ed linear
Action
90° rotation
Sizes
2” to 24”
Type of end fi tting
for use with ANSI 125/150 fl anges
Materials:
Body
Body fi nish
Disc
Seat
Shaft
O-ring
Upper bushing
Middle bushings
Lower bushing
ductile iron ASTM A536
epoxy powder coated
304 stainless steel
EPDM standard
416 stainless steel
EPDM
RPTFE
RPTFE
RPTFE
Media temperature range
-22°F to 250°F [-30°C to 120°C]
Operation ambient
temperature range
-22°F to 122°F [-30°C to 50°C]
Body pressure rating
ASME/ANSI Class 125/150
(200 psi at -30°F to 275°F)
Close-off pressure
200 psi (2”-12”), 150 psi (14”-24”)
Rangeability
10:1 (for 30° to 70° range)
Maximum Velocity
12 FPS
• 200 psi (2” to 12”) and 150 psi (14”-30”) bubble tight shut-off
• Long stem design allows for 2” insulation
• Valve face-to-face dimensions comply with API 609 & MSS-SP-67
• Completely assembled and tested, ready for installation
• Tees comply with ASME/ANSI B16.1 Class 125 fl anges
Application
These valves are designed to meet the needs of HVAC and commercial
applications requiring bubble tight shut off for liquids. Typical applications
include chiller isolation, cooling tower isolation, change-over systems, large
air handler coil control, bypass and process control applications. The large
C
v
values provide for an economical control valve solution for larger fl ow
applications. Designed for use in Victaulic piping systems when mated to
Victaulic 41 series fl ange nipples. Fail safe operation is possible with NSV-SY
series battery backup systems.
Jobsite Note
Valves should be stored in a weather protected area prior to construction.
Complete installation recommendations can be found in Belimo’s Installation
and Maintenance Instructions for F6/F7…HD/HDU Butterfl y Valves.
Valve
Nominal Size
Type
Suitable Actuators
C
v
90°
C
v
60°
IN
DN
[mm]
2-way
Spring
Non-Spring
115
44
2”
50
F750HD
AF Series
AM
GM Series
SY Series
196
75
2½”
65
F765HD
302
116
3”
80
F780HD
600
230
4”
100
F7100HD
1022
392
5”
125
F7125HD
1579
605
6”
150
F7150HD
3136 1202
8”
200
F7200HD
5340 2047
10”
250
F7250HD
8250 3062
12”
300
F7300HD
11917 4568
14”
350
F7350HD
16388 6282
16”
400
F7400HD
21705 8320
18”
450
F7450HD
27908 10698 20”
500
F7500HD
43116 16528 24”
600
F7600HD
MOD
ON/OFF
Valve
Size
C
v
10°
20°
30°
40°
50°
60°
70°
80°
90°
F750HD
2”
115
.06
3
7
15
27
44
70
105
115
F765HD
2½”
196
.10
6
12
25
45
75
119
178
196
F780HD
3”
302
.20
9
18
39
70
116
183
275
302
F7100HD
4”
600
.30
17
36
78
139
230
364
546
600
F7125HD
5”
1022
.50
29
61
133
237
392
620
930
1022
F7150HD
6”
1579
.80
45
95
205
366
605
958
1437
1579
F7200HD
8”
3136
2
89
188
408
727
1202
1903
2854
3136
F7250HD
10”
5340
3
151
320
694
1237
2047
3240
4859
5340
F7300HD
12”
8250
4
234
495
1072
1911
3062
5005
7507
8250
F7350HD
14”
11917
6
338
715
1549
2761
4568
7230
10844
11917
F7400HD
16”
16388
8
464
983
2130
3797
6282
9942
14913
16388
F7450HD
18”
21705
11
615
1302
2822
5028
8320
13168
19752
21705
F7500HD
20”
27908
14
791
1674
3628
6465
10698
16931
25396
27908
F7600HD
24”
43116
22
1222
2587
5605
9989
16528
26157
39236
43116
0
