800-543-9038 USA

866-805-7089 CANADA

203-791-8396 LATIN AMERICA

14

Wiring for Damper Actuators and Control Valves
On/Off, 24V, 120/230V

Observe class 1 and class 2 wiring restrictions.

Transformer sizing = SY actuator draw X 1.25 (safety margin)
(Ex. SY2-24 requires 3.0A x 1.25 = 3.75A,
3.75A X 24 VAC = 90VA Transformer).

Indicates an action or condition that may cause irreversible
damage to the actuator(s) or associated equipment.

Equipment damage!
Power consumption and input impedance must be observed.

CAUTION

Indicates a potentially hazardous situation which, if not avoided,
may result in minor or moderate injury. It may also be used to
alert against unsafe practices.

Warnings and Cautions appear at appropriate sections throughout
this manual. Read these carefully.

Hazard Identification

INSTALLATION NOTES

NOTES SY1…5-24

Each actuator should be powered by a single, isolated
control transformer.

s

s

24 VAC Transformer

Line
Volts

Open

Close

G Ground

1 Common

3 Open

4 Closed

5

Connect to #1 for fully

open indication

6

Connect to #1 for fully

closed indication

7

G Ground

1 Common

3 Open

4 Closed

5

Connect to #1 for fully

open indication

6

Connect to #1 for fully

closed indication

7

HTR

A

B

C

D

E

F

LS3

A-C

(Open Indication)

LS4

D-F

(Closed Indication)

Contact Rating: 5A 250 VAC Max.

SY2…5-24

120 and 230 VAC

G

Open

Close

G

N L1

H L2

HTR

A

B

C

D

E

F

LS3

A-C

(Open Indication)

LS4

D-F

(Closed Indication)

Contact Rating: 5A 250 VAC Max.

SY2…12-110 (220)

NOTES SY1…12-110 (220)

s

SY1-24

A

B

C

E

F

Contact Rating: 5A 125 VAC Max.
3A 250 VAC Max.

A-B (Open Indication)

LS4

LS3

A-E (Closed Indication)

SY1-110 (220)

A

B

C

E

F

Contact Rating: 5A 125 VAC Max.
3A 250 VAC Max.

A-B (Open Indication)

LS4

LS3

A-E (Closed Indication)

SY1 Contact Arrangements

33

33

W

546

Actuators: SY1-24 SY1-110 SY2...12-110 SY2...12-220
