Dimensions with 2-Way Valve
A
B
C
D
BHC
BF2WUDIM_ABF2WUDIM
AF Actuators, Multi-Function Technology
Models
AFX24-MFT-X1
AFX24-MFT-S-X1 w/built-in Aux. Switches
Dimensions (Inches)
Fail Safe (psi)
Valve
Size
A
B
C
D(Max)
BHC
AF
2*AF
F650HD
2”
1.65
9.00
9.00
19.50
4.75
200
F650HDU
2”
1.65
9.00
9.00
19.50
4.75
50
F665HD
2½”
1.76
9.00
9.00
20.00
5.50
200
F665HDU
2½”
1.76
9.00
9.00
20.00
5.50
50
F680HD
3”
1.78
9.00
9.00
20.50
6.00
500
F680HDU
3”
1.78
9.00
9.00
20.50
6.00
50
F6100HDU
4”
2.05
9.00
9.00
21.00
7.50
50
F6125HDU
5”
2.14
9.00
9.00
22.00
8.50
50
F650-150SHP
2”
1.75
9.00
9.00
19.50
4.75
150
F665-150SHP
2½”
1.88
9.00
9.00
20.00
5.50
150
F680-150SHP
3”
1.92
9.00
9.00
20.50
6.00
150
F6100-150SHP
4”
2.13
9.00
9.00
21.00
7.50
150
F650-300SHP
2”
1.75
9.00
9.00
19.50
5.00
150
F665-300SHP
2½”
1.88
9.00
9.00
20.00
5.88
150
F680-300SHP
3”
1.92
9.00
9.00
20.50
6.63
150
F6100-300SHP
4”
2.13
9.00
9.00
21.00
7.88
150
Dimensions with 3-Way Valve
10
10
D
A
B
C
Dimensions (Inches)
Fail Safe (psi)
Valve
Size
A
B
C
D(Max)
BHC
AF
2*AF
F750HD
2”
4.50
6.15
6.15
15.50
4.75
200
F750HDU
2”
4.50
6.15
6.15
15.50
4.75
50
F765HD
2½”
5.00
6.76
6.76
16.00
5.50
200
F765HDU
2½”
5.00
6.76
6.76
16.00
5.50
50
F780HDU
3”
5.50
7.28
7.28
16.25
6.00
50
HS
DW
G
P11
Technical Data
Power supply
24 VAC, +/- 20%, 50/60 Hz
24 VDC, +20% / -10%
Power
running 7.5 W
consumption
holding 3 W
Transformer sizing
10 VA (Class 2 power source)
Electrical connection
AFX...
3 ft [1m] default, 10 ft [3m] or 16 ft [5m] 18 GA
appliance or plenum cables, with or without 1/2” conduit
connector
-S models: two 3 ft [1m] default, 10 ft [3m] or
16 ft [5m] appliance cables with or without 1/2" conduit
connectors
Overload protection
electronic throughout 0 to 95° rotation
Operating range Y*
2 to 10 VDC, 4 to 20 mA (default)
variable (VDC, PWM, floating point, on/off)
Input impedance
100 k
Ω for 2 to 10 VDC (0.1 mA)
500
Ω for 4 to 20 mA
1500
Ω for PWM, floating point and on/off control
Feedback output U*
2 to 10 VDC, 0.5 mA max
Torque
minimum 180 in-lb (20 Nm)
Direction of
spring reversible with cw/ccw mounting
rotation*
motor reversible with built-in switch
Mechanical
angle of rotation*
95° (adjustable with mechanical end stop, 35° to 95°)
Running time
spring <20 sec @ -4°F to 122°F [-20° C to 50° C];
<60 sec @ -22°F [-30° C]
motor* 150 seconds (default), variable (70 to 220 seconds)
Angle of Rotation
adaptation
off (default)
Override control*
min position = 0%
mid. position = 50%
max. position = 100%
Position indication
visual indicator, 0° to 95°
(0° is spring return position)
Manual override
5 mm hex crank (
³⁄₁₆" Allen), supplied
Humidity
max. 95% RH, non-condensing
Ambient temperature
-22 to 122° F (-30 to 50° C)
Storage temperature
-40 to 176° F (-40 to 80° C)
Housing
NEMA 2, IP54, Enclosure Type 2
Housing material
zinc coated metal and plastic casing
Noise level
≤40dB(A) motor @ 150 seconds, run time dependent
≤62dB(A) spring return
Agency listings †
cULus acc. to UL60730-1A/-2-14, CAN/CSA E60730-
1:02, CE acc. to 2004/108/EC & 2006/95/EC
Quality standard
ISO 9001
Servicing
maintenance free
Weight
4.6 lbs. (1.9 kg), 4.9 lbs. (2 kg) with switch
* Variable when configured with MFT options
† Rated Impulse Voltage 800V, Type of action 1.AA (1.AA.B for -S version), Control Pollution Degree 3.
Programmed for 70 sec motor run time. At 150 sec motor run time, transformer sizing
is 8.5 VA and power consumption is 6 W running / 3 W holding.
i
AFX24-MFT-S-X1
Auxiliary switches
2 x SPDT 3A (0.5A) @ 250 VAC, UL approved
one set at +10°, one adjustable 10° to 90°
0
