F6…HDU Butterfl y Valves 2”–12” Ductile Iron Lug Body
Resilient Seat, 304 Stainless Disc
Technical Data
Service
chilled, hot water, 60% glycol
Flow characteristic
modifi ed equal percentage
Action
90° rotation
Sizes
2” to 12”
Type of end fi tting
for use with ANSI Class 125/150 fl anges
Materials
Body
Body fi nish
Disc
Seat
Shaft
O-ring
Upper bushing
Middle bushings
Lower bushing
ductile iron ASTM A536
epoxy powder coated
304 stainless steel
EPDM
416 stainless steel
EPDM
RPTFE
RPTFE
RPTFE
Media temperature range
-22°F to 250°F [-30°C to 120°C]
Operation ambient
temperature range
-22°F to 122°F [-30°C to 50°C]
Body pressure rating
ASME/ANSI Class 125/150
(200 psi at -30°F to 275°F)
Close-off pressure
50 psi
Rangeability
10:1 (for 30° to 70° range)
Maximum velocity
12 FPS
• 50 psi bubble tight shut-off
• Long stem design allows for 2” insulation
• Valve face-to-face dimensions comply with API 609 & MSS-SP-67
• Completely assembled and tested, ready for installation
Application
These valves are designed to meet the needs of HVAC and commercial
applications requiring bubble tight shut-off for liquids. Typical applications
include chiller isolation, cooling tower isolation, change-over systems, large
air handler coil control, bypass and process control applications. The large
C
v
values provide for an economical control valve solution for larger fl ow
applications. Designed for use in Victaulic piping systems when mated to
Victaulic 41 series fl ange nipples.
Jobsite Note
Valves should be stored in a weather protected area prior to construction.
Complete installation recommendations can be found in Belimo’s Installation
and Maintenance Instructions for F6/F7…HD/HDU Butterfl y Valves.
Valve
Nominal Size
Type
Suitable Actuators
C
v
90°
C
v
60°
IN
DN
[mm]
2-way
Spring
Non-Spring
115
44
2”
50
F650HDU
AF
Series
AM
Series
SY Series
196
75
2½”
65
F665HDU
302
116
3”
80
F680HDU
GM
GM
600
230
4”
100
F6100HDU
1022
392
5”
125
F6125HDU
1579
605
6”
150
F6150HDU
3136 1202
8”
200
F6200HDU
5340 2047
10”
250
F6250HDU
8250 3062
12”
300
F6300HDU
MOD
ON/OFF
Valve
Size
C
v
10°
20°
30°
40°
50°
60°
70°
80°
90°
F650HDU
2”
115
.06
3
7
15
27
44
70
105
115
F665HDU
2½”
196
.10
6
12
25
45
75
119
178
196
F680HDU
3”
302
.20
9
18
39
70
116
183
275
302
F6100HDU
4”
600
.30
17
36
78
139
230
364
546
600
F6125HDU
5”
1022
.50
29
61
133
237
392
620
930
1022
F6150HDU
6”
1579
.80
45
95
205
366
605
958
1437
1579
F6200HDU
8”
3136
2
89
188
408
727
1202
1903
2854
3136
F6250HDU
10”
5340
3
151
320
694
1237
2047
3240
4859
5340
F6300HDU
12”
8250
4
234
495
1072
1911
3062
5005
7507
8250
0
