Models

AF24 US

AF24-S US

w/built-in Aux. Switches

AF120 US

AF120-S US

w/built-in Aux. Switches

Technical Data

Control

on/off

Power consumption

AF24(-S) US

running 5 W

holding 1.5 W

AF120(-S) US

running 6 W

holding 2.3 W

Transformer sizing

10 VA, class 2 power

Electrical connection

3 ft, 18 GA appliance cables
(-S model has 2 cables)
½” conduit connector

Electrical protection

120 V actuators double insulated

Overload protection

electronic throughout 0° to 95° rotation

Angle of rotation

95°

Position indication

visual indicator

Manual override

hex crank

Running time

control 150 sec. independent of load

spring < 20 sec.

Ambient temperature

-22° F to 122° F [-30° C to 50° C]

Housing

NEMA 2 / IP54

Agency listings

UL 873, CSA C22.2 No. 24 certifi ed, CE

Noise level

max. 45 dB(A)

AF...-S US
Auxiliary switches

2 x SPDT, 7A (2.5A) @ 250 VAC, UL listed,
one switch is fi xed at +5°, one is adjustable
25° to 85° (double insulated)

AF Actuators, On/Off

Dimensions with 2-Way Valve

A

B

C

D

BHC

B

F2WUDIM_A

Dimensions (Inches)

Fail Safe (psi)

Valve

Size

A

B

C

D(Max)

BHC

AF

2*AF

F650HD

2”

1.65

9.00

9.00

19.50

4.75

200

F650HDU

2”

1.65

9.00

9.00

19.50

4.75

50

F665HD

2½”

1.76

9.00

9.00

20.00

5.50

200

F665HDU

2½”

1.76

9.00

9.00

20.00

5.50

50

F680HD

3”

1.78

9.00

9.00

20.50

6.00

200

F680HDU

3”

1.78

9.00

9.00

20.50

6.00

50

F6100HDU

4”

2.05

9.00

9.00

21.00

7.50

50

F6125HDU

5”

2.14

9.00

9.00

22.00

8.50

50

F650-150SHP

2”

1.75

9.00

9.00

19.50

4.75

150

F665-150SHP

2½”

1.88

9.00

9.00

20.00

5.50

150

F680-150SHP

3”

1.92

9.00

9.00

20.50

6.00

150

F6100-150SHP

4”

2.13

9.00

9.00

21.00

7.50

150

F650-300SHP

2”

1.75

9.00

9.00

19.50

5.00

150

F665-300SHP

2½”

1.88

9.00

9.00

20.00

5.88

150

F680-300SHP

3”

1.92

9.00

9.00

20.50

6.63

150

F6100-300SHP

4”

2.13

9.00

9.00

21.00

7.88

150

0
