- PROFINET Communication Unit DL-PN1 User's Manual (IB) -
130
Measurement mode
DINT
R/W
0
0: Percent mode
1: Dimension mode
131
Received/Blocked light mode
DINT
R/W
0
0: Received light mode
1: Blocked light mode
132
Reserved for system
133
Averaging/High-pass filter
DINT
R/W
5
Averaging
0:
1 time
1:
2 times
2:
4 times
3:
8 times
4:
16 times
5:
64 times
6:
256 times
7:
1024 times
8:
4096 times
9:
16384 times
High-pass filter
10: 0.1Hz
11: 0.2Hz
12: 0.5Hz
13: 1Hz
14: 2Hz
15: 5Hz
16: 10Hz
17: 20Hz
18: 50Hz
19: 100Hz
134
Output mode
DINT
R/W
0
0: N.O (Normal open)
1: N.C (Normal close)
135
Reserved for system
136
Hold function setting
DINT
R/W
0
0: Sample hold
1: Peak hold
2: Bottom hold
3: Peak-to-peak hold
4: Auto peak hold
5: Auto bottom hold
137
Auto hold trigger level
*7
DINT
R/W
+90.00
-999.99 to +999.99
138
Timing input setting
DINT
R/W
0
0: Level
1: Edge
139
Delay Timer
DINT
R/W
0
0: OFF
1: On delay
2: Off delay
3: One-shot
140
Timer duration
DINT
R/W
60
1 to 9999
141
Hysteresis
DINT
R/W
0.00
0.00 to 999.99
142
Analog output scaling
*17
*19
DINT
R/W
0
0: Initial state
1: Free range
143
Analog output upper limit
*7
*17
*19
DINT
R/W
+100.00
-999.99 to +999.99
144
Analog output lower limit
*7
*17
*19
DINT
R/W
0
-999.99 to +999.99
145
External input setting
*18
DINT
R/W
0
0: Default
1: User setting
