COP-USA DVR2304SE-B - Manual (Page 40)

Digital Video Recorder User Manual
34
Fig 4-30 Network Configuration-Sub Stream
4.6.3 Email
Step 1: Enter into MenuSetupNetworkEmail tab. Refer to Fig 4-31:
SMTP Server/Port: The name and port number of SMTP server. After selecting “This
server requires a secure connection (SSL)”, user can setup mail servers (such as Gmail)
according to actual needs.
Send address/password: Sender‟s email address/password
Receive address: Receiver‟s email address. Here user can add at least three mail
addresses.
Click TEST button to test the validity of the mailbox.
Attaching image: If selected, the system will attach images when sending the emails.
Fig 4-31 Network Configuration-Email
Parameter Meaning
FPS Range from: 1-6 (PAL)
Resolution Support CIF
Quality The quality of the clients‟ image. The higher the value
is, the clearer the record image. Six options: lowest,
lower, low, medium, higher and highest.
Encode VBR and CBR
Max bit
rate
Range from: 32 Kbps~768 Kbps
