Digital Video Recorder User Manual
9
Item Name Description
10 USB port Connect USB mouse or connect external USB devices
11 DC12V POWER INPUT
12 Audio out Audio output, connect to the sound box
13 Video out Connect to monitor
14 Spot out Connect to monitor as an AUX output channel by channel. Video would be displayed without OSD.
2.4 Remote Controller
It uses two AAA size batteries:
Step1: Open the battery cover of the Remote Controller
Step2: Place batteries. Please take care the polarity (+ and -)
Step3: Replace the battery cover
Key point to check in case the remote doesn’t work.
1. Check batteries polarity
2. Check the remaining charge in the batteries
3. Check IR controller sensor is mask
If it still doesn't work, Please change a new remote controller to try, or contact your dealers
The interface of remote controller is shown in Fig 2-6 Remote Controller.
Note: Remote controller can be selected depending on the product model. Here we will take the bigger remote controller as an
example to describe.
