Digital Video Recorder User Manual
5
Item Type Name Description
1
Work state
indicator
Power Power indicator, when connection , the light is blue
HDD When HDD is writing and reading , the light is blue
Net When access to network , the light is blue
Backup When backup files and data, the light is blue
Play When playing video, the light is blue
REC When recording, the light is blue
2
Compound
button
MENU/+ 1. Enter menu in live 2. Increase the value in setup
BACKUP/- 1. Decrease the value in setup 2. Enter backup mode in live
RECORD/FOCUS 1. Record manually 2. FOCUS function enables at PTZ mode.
REW/SPEED 1. Rewind key 2. SPEED function enables at PTZ mode
SEARCH/ZOOM 1. Enter search mode 2.ZOOM function enables at PTZ mode.
PLAY /IRIS 1. Enter play interface 2. IRIS function enables at PTZ mode
FF/ P.T.Z. 1. Fast forward 2. Enter PTZ mode in live
STOP/ESC 1. Quit play mode 2. Exit the current interface or status
3
Digital
button
1-9 Input number 1-9 or choose camera
0/10+ Input number0, 10 and the above number together with other digital keys
4 Input button
Direction button Change direction to select items
Multi-screen Change screen display mode like1/4/9/16 channel
Enter button Confirm selection
5 IR receiver IR For remote controller
6 USB USB port
To connect external USB devices like USB flash, USB HDD for backup or update firmware;
or connect to USB mouse
7 POWER POWER Switch off
