Digital Video Recorder User Manual
21
Fig 4-6 Live ConfigurationLive Fig 4-7 Live-Color Adjustment
4.2.2 Main Monitor
Step1: Enter into MenuSetupLiveMain Monitor tab. Refer to Fig 4-8:
Step2: Select split mode: 1Ч1、2Ч2、2Ч3、3Ч3、4Ч4 and map the channel
Step3: Set the dwell time.
Step4: Select the split mode and then setup current picture group. Click button
to setup the previous channel groups of dwell picture.
Click button to set the latter channel groups of dwell picture.
Step5: Click “Default” to restore default setting; click “Apply” to save the setting;
click “Exit” to exit the current interface.
Fig 4-8 Live Configuration-Main Monitor
