NVMS-5000 User manual
7
2.93GHz or above/4GB DDR3/NV
GT430 or AMD HD 6570 or above,
above 512MB GDDR5 Memory
(recommend 1GB GDDR5 memory)
/500GB SATA/100M NIC
Professional/ Ultimate
2 TV-Wall Server Use 8/4-ch decoder
Windows 7/Windows
XP 32 bit
It is up to the
number of the
decoding channel
and output display
screen
3
Config Client
TV-Wall Client
z CPU˖2G or above
z Memory˖2GB DDR3
z HDD˖500GB SATA
z NI˖1000M
Windows XPSP3 32bit
Professional
/Windows 7 SP1 32bit
Professional/Ultimate
1
2.2 Requirement for Firewall
In order to ensure the network security, it is necessary for the system to setup firewall. All monitor ports shall be
opened in the installed servers. The open ports are as follows:
Server Port Type Port Server Port Type Port
Authentication server Internal port 6003 Web server Service port 8088
Media transfer server
Internal port 6006 Storage server Internal port 6009
Auto report 2009 Alarm server Internal port 6033
E-map server Internal port 6039
Note: The above-mentioned ports are the default internal ports of servers. If all these ports are modified,
these open ports shall be modified accordingly in the firewall configuration.
2.3 Confirm Installation Environment
Item Checkup Standard
Hardware Checkup whether the hardware meets the standard required. ˄including CPU, memory, HDD, etc.˅
Software
Checkup whether the software meets the standard required. ˄including the type and version of the
operation system, NVMS-5000 version, etc. ˅
Front-end device Checkup whether the device access is normal and the DVR version is 3.1.9 or above.
Firewall setup Checkup whether those open ports of firewall meet the standard required.
Network Checkup whether the networks of front-end devices and center equipments are normal.
TCP/IP config Checkup whether the settings of IP address, subnet mask, gateway and DNS correct.
