COP-USA NVMS 5000 User Manual
Page 16
NVMS-5000
User manual
16
z If the authentication server runs in LANˈplease input the LAN IP address and port of the authentication server.
z If the authentication server runs in WAN, please input the WAN IP address or select ‘Domain’ to input the domain
name and port of the authentication server.
After inputting all information, please click ‘OK’ button and then click ‘Close’ button to return to the login
window. Then click ‘Login’ button to enter into the Config Client interface.
Config Client includes three modules: Device and Server, Account and Permission, System and Security.
Click the relevant icon or blue letters to enter into the relevant module.
Device and Server interface includes adding, modifying and deleting device, Media Server, Storage Server, TV
᤹
᤹䫞
ਜ਼
ਜ਼ѹ
Return to the previous
interface
Enter into the next
interface
Display the server
information and
configure parameters
Shrink the window
Minimize the window
Exit
