NVMS-5000 User manual
6
NO. Server Function IP address
1 Authentication server Authenticate devices ˄including Web˅ 192.168.6.67
2 Media transfer server Transfer images 192.168.6.68
3 Storage server Image storage 192.168.6.69
4 Alarm server Alarm handling 192.168.6.70
5 Emap server Emap application 192.168.6.71
Note ˖If servers are installed in the same PC, these servers shall have the same IP address.
1.3 NVMS-5000 Version Introduction
Version Average signal access Max signal access
NVMS-5000 v1.2 300-400 channels video signals 30000-ch video signals
2 Configuration Requirement
2.1 Software and Hardware Configuration Requirement
2.1.1 S&H Config Requirement for Contorl Center
No.
NVMS-5000
components
Recommendation for hardware
configuration
Recommendation
for software
configuration
Number
1
Authentication
server/
Media server/
Storage server/
Alarm Server/
E-map Server
z CPU˖XEON 3430 2.40GHz/Core
4,8M
z Main board˖Intel 3420
z Memory˖4GB DDR3 ECC
z HDD˖500GB SATA
z NIC˖2×1000M˄More NICs need if
more networks access ˅
Windows server
2003 32 bit
/Windows server
2008 32bit
It is up to the video format and
the number of channel
previewing simultaneously for
media server and storage server.
Authentication Server: 1
Alarm Server:1
E-Map Server: 1
2 HDD
z Capacity: 500GB/1TB/2TB
--
It is up to the stream, channel and
time of the storage video
3
IP-SAN
(optional)
z Supports 12/16/24 SATAs
--
It is up to the number of the
HDD
2.1.2 S&H Config Requirement for Background Monitor
No. NVMS-5000
components
Recommendation for hardware
configuration
Recommendation for
software configuration
Number
1 Monitor Client Intel Core i3 530 double core Windows 7 SP1 32bit As required by user
