NVMS-5000 User manual
57
Area Descriptions:
Area Description Area Description
1 Playback Area 2 Toolbar
3 Record time Area 4 Resources Area
5 Time search or type search Area
Buttons Description of Area 2
Icon Description
Screen mode. 1,4,9,16,25 channels are optional
Close playback of all channels
Full screen
Play
Pause
Stop
Playback by single frame. When playback, click button firstly
and then click this button to play frame by frame.
Backup the start time
Backup the end time
Download
Event list. Click this button to pop up the event list
Playback speed bar
Toolbar on Playback Window:
Icon Description Icon Description
Close playback Snap
Open/close audio Zoom in
Fit to window
Right button functions:
Menu Description Menu Description
Snap Snap picture Enable Audio Enable or close audio
Download By
Time
To download record by
time search
Close Channel Close single channel preview
Full Screen To display in full screen
In the playback interface, select date and record type, then drag the camera to the right display window for playing. You
can click button to search the record file, then click button to playback.
Playback Record type includes manual record, motion detection record, schedule record, and sensor record.
