11 Equipment and Accessories
51
11.3 Viability option
The NucleoCounter SP-100 can also be supplied with the viability option, which can be
used for the estimation of the number of viable sperm cells in a semen sample. Contact
ChemoMetec A/S for further information.
11.4 Dry compressed air
Dry, compressed air (KENAIR Air Duster - CFC Free) is used for removal of dust from the
optical system of the NucleoCounter SP-100 (refer to
Section 7 ).
The item can be obtained from Kenro Ltd, Greenbridge Road, Swindon SN3 3LH, UK. Tel:
+44 (0) 1793 615836, E-mail: [email protected]. Alternatively the item, or a similar
item, might be available in your own country through local dealers.
11.5 Power supply
The NucleoCounter SP-100 shall only be used with one of the following external
power supplies:
•
Power supply Class I, Proton Electronic Industrial Co. Ltd., model SPN-260-12,
input rated 100-240 Vac, 50-60Hz, 1.6 A. Output rated 12 Vdc, 4.3 A.
•
Power supply Class I, Powerbox Europe AB, model EBH 03 131, input rated
100-240 Vac, 47-63 Hz, 0.8A. Output rated 11-13 Vdc, 2.7 A.
•
Power supply Class II, Celetron USA Inc., model ZVC40LT12E, input rated 100-
240 Vac, 50-60Hz, 1.2 A. Output rated 12 Vdc, 3.3 A.
The detachable power supply cord set and appliance inlet of the external power
supply are considered as the disconnecting device.
Contact ChemoMetec A/S for information on order of a specific power supply listed
above.
11.6 Mains Power cord
Detachable power supply cord set for the Class I specified power supplies:
For US 125 Vac
UL listed, type SVT, rated min. 60C, 18 AWG, 3 conductors. Provided with molded-on
grounding-type (NEMA 5-15P) attachment plug, rated min. 125 Vac, min. 2.5A. Opposite
end terminates in molded on, IEC320 style connector, rated min. 125 Vac, min. 2.5 A.
For Europe 250Vac
