5 Operation of NucleoCounter SP-100
15
5 Operation of NucleoCounter SP-100
In this section the operation of the NucleoCounter SP-100 is described.
5.1 Generel remarks
Please pay attention to that a command like F0 is typed in by pressing the F-key
(function key) followed by “ 0”.
When pressing the F-key the following display text appears (if the instrument is in the
“ Ready” status or the “Result” status):
Display Text Type 4A
Function Function Function Function
F_ F_ F_ F_
↵ ↵ ↵ ↵ select select select select
Figure Figure Figure Figure 15 15 15 15. The instrument is ready for typing in the function number....
When typing in “ 0” the display will show:
Display Text Type 4B
Function Function Function Function
F0 F0 F0 F0
↵ ↵ ↵ ↵ select select select select
Figure Figure Figure Figure 16 16 16 16. The F0 function can be selected by pressing the “ ↵ ↵ ↵ ↵ ” button.... Figure Figure Figure Figure 29 29 29 29 shows
what is displayed when “ ↵ ↵ ↵ ↵ ” is pressed.
If the function does not exist the following text is displayed when pressing “ ↵ ↵ ↵ ↵ ”:
Display Text Type 5
Invalid Invalid Invalid Invalid
function function function function
Figure Figure Figure Figure 17 17 17 17. The function that has been chosen does not exist. Press any key.
