5 Operation of NucleoCounter SP-100
31
Figure Figure Figure Figure 58 58 58 58. . . . Illustration of how to grip and insert the cassette into the insertion slit
The instrument is delivered with two lids. The largest of the two lids is shown in the
figure above. This lid can be used as described above but in order to protect the
insertion area from dust and dirt this lid must be placed on the instrument in the closed
position when the instrument in not in use. The smallest of the two lids (see the figure
below) is more easy to handle and the lid can replace the large lid if it is more
convenient during a measurement session.
However, replace the small lid with the
large lid when the session is over.
Figure Figure Figure Figure 59 59 59 59. . . . NucleoCounter SP-100 with the small version of the lid which can be used
when many samples are being analyzed
