NIRCal 5.5 Software Manual
256 NIRCal 5.5 Manual, Version A
3.21.5 Choose [x][y] Independent
Applies to 2D scatter plots only. This means that the value of each cell in one column or row of matrix
1 is plotted against the value of the same cell in any column or row of matrix 2. If you open the
"Original Property" plot and transpose it you will be able to plot one property against another and
check for dependencies.
Related Topic:
Choose [xy] Independent
3.21.6 Choose [xy] Independent
Applies to 2D scatter plots only. This means that the value of each cell in one column or row of matrix
1 is plotted against the value of the same cell in the same column or row of matrix 2. In the "True
against Predicted" plot this means that the same property is displayed on x and y axis.
Related Topic:
Choose [x][y] Independent
3.21.7 Clear Selection
Removes all objects from the current selection.
Changes to the current selection do not affect your calibration or validation set.
3.21.8 Colors
The following color models can be used with the top view plot and in 3D surface plot.
nirBone
Grayscale with a light touch of
blue.
nirHot Low values are black,
intermediate red and high values
are yellow
nirJet Contrast enhancing color model.
nirCool Low values are ice blue,
intermediate blue and high
values are pink.
nirCopper Monochrome graduation with a
coppertone.
nirFlag Extremely contrast enhancing
color model.
nirGray Gray scale palette.
nirHSV Contrast enhancing color model.
St.palette
3.21.9 Copy Plot to Clipboard
Copies the plot to the clipboard.
3.21.10 Copy Selection To
Delete the contents of the chosen set and replace it with the objects currently selected in the plot.
CAUTION: This action will change the contents of your validation or calibration set if you copy data to
these sets.
Add Selection to Set , Load Selection from Set , Remove Selection from
