6 Operation
38 B-395 Pro Operation Manual, Version C
6 .3 Menu structure of the control unit
The figure below shows a schematic overview of all menus of the Encapsulator B-395 Pro, each with
the available functionality.
Lower Screen - main menu
Pump On/Off
Stirrer On/Off
Home/Turbo button
Pressure value
Set Pump | Set Stirrer
Stirrer [%]
Stirrer On/Off
Set Stirrer Speed
Syringe Pump
Pump On/Off
Set Pumping Rate
Cal ml/min
Syringe Pump Calibration
Select Syringe type
Syringe Pump Calibration
Start Timer: Collection of Liquid
for 60 sec.
Syringe Pump Calibration
Set Pumped Liquid Store
Syringe Pump Calibration
Store value Yes/No
Upper Screen - main menu
Frequency On/Off
Electrode On/Off
Store function
Set Freq. | Set Elect. | More
Electrode [V]
Electrode On/Off
Set Electrode
Frequency [Hz]
Frequency On/Off
Set Frequency
more Frequency
Set Light Intensity
Set Amplitude
Figure 6-1: Menu structure of the control unit
