5 Putting into operation
34 B-395 Pro Operation Manual, Version C
Figure 5-21: CN bead producing unit with set of 7 shell nozzles. The following nozzle apertures are standard:
0.20, 0.30, 0.4, 0.50, 0.60, 0.70 and 0.90 mm.
1 4 5 6
9 8
3
7
2
10
Figure 5-22: Single parts of the CN bead producing unit
a Screw M3×6
 Luer lock female
 Pre-filter grid 50 µm mesh, D= 7 mm
 O-Ring 14.0×1.78
 Screw M3×8  Screw M3×25
 O-Ring 3.68×1.78
 CN pulsation body
 O-Ring 12.42×1.78
 CN membrane holder
