5 Putting into operation
29 B-395 Pro Operation Manual, Version C
5 .4 .3 Bead collecting flask
After finishing bead production and bead processing, the beads are directly transferred through the
bead harvesting valve into the bead collecting flask. The beads can then be transported aseptically to
any other container. Figure 5-15 shows the disassembled and assembled bead collecting flask.
1 4 3 2
6 7 5
Figure 5-15: Bead collecting flask for sterile havesting and transportation of the produced
beads and capsules. The bead collecting flask is attached to the bead harvesting valve of
the reaction vessel.
a 250 mL flask
 Air filter, see Fig. 5-10
 Tube clamp
 Silicone tube 10×14  Plate of collecting flask
 O-Ring (31.42×2.62)
 Cap with hole
