KX-P6100 Status Display
Setup Menu
This menu displays the Change Printer Settings screen
Edge Enhancement
O Off
O O Light
®] Medium
O Dark
Power Saving Mode
® On
pq
O Off
Change Printer Settings
Connect Port
® LPT1
C' LPT2
O LPT3
p TonrSavR (TM) —
® Off
O Medium
O Dark
OK
Cancei
Default
P Density
O Level 1
O Level 2
® Level 3
O Level 4
O Level 5
Edge Enhancement Technology (EET) liSl
With Edge Enhancement turned on, the KX-P6100 will
smooth the jagged edges of text and line art, giving the
output a very high quality appearance There are three
settings Light, Medium, and Dark The factory default
setting IS Medium If the EET setting is too dark, the
edges appear to bulge
The demo page of the test print (P 16) has an Edge
Enhancement test block As a general guideline, select
the EET setting so as to make this block look like a
uniform gray block with no vertical lines in it as shown in
Figure 2
If there are white vertical lines in the test print (Figure 1),
set the EET to a darker setting If there are dark vertical
lines in the test print (Figure 3), set the EET to a lighter
setting
[ i n
i'
n
j l
f
!
Jl
tl
1 1
i
Figure 1 Figure 2 Figure 3
Power Saving Mode Li
With Power Saving Mode turned on, you can save
energy by instructing your printer to enter a low power
consumption mode if you do not use it for 15 minutes
For USA: To conserve energy and reduce operating
cost, the printer is equipped with a programmable power
save feature The printer is factory set with the power
save feature turned on and programmed to 15 minutes
to comply with EPA’s Energy Star requirements
Connect Port
The Connect Port option lets you select a different
parallel port for your printer Depending on what your PC
has available, you can choose LPT 1, LPT2, or LPT3
TonrSavR Mode iOl
With TonrSavR turned on, the KX-P6100 will reduce the
amount of toner used to print the image Black areas and
text are replaced by a light gray shading
• Light. Text and objects on the page have a black
outline along their left edge
• Medium. Text and graphics have a black outline
along their left and right edges
• Dark: Text and graphics have a black outline along
all edges This setting is recommended over Light and
Medium if you expect to fax or photocopy the docu­
ment
• Off This IS the default setting and is recommended
for the highest quality Output appears normal
Density B
The Density option lets you choose from level 1 to level
5 To make print lighter, choose a lower level button To
make print darker, choose a higher level button
Note
• The EET, Power Saving Mode, TonrSavR Mode
and Density features also appear on the
Panasonic KX-P6100 Status Display Toolbar
O
■o
0)
0)
(D
C
10
0
3
c
29
