Operating various settings for this unit (Setup menu)
• The speaker configuration includes items lor defining a speaker size;
“Large" or “Small". “Large" and “Small" refer to speakers with woofer
diameters 16 cm or larger and smaller than 16 cm. respectively.
Extra Speaker Assignment
Choices: Zone2'^, Presence, None
Selects the application for the EXTRA SP terminals.
Zone2 Assigns the EXTRA SP terminals for the
speakers in the second zone.
Presence Assigns the EXTRA SP terminals for the
presence speakers.
None Disables the EXTRA SP terminals.
Note
• When setling "Extra SP .Assign" to "Zonc2" or "Presence", the surround back
channel signals for main output is separately output from other channels.
LFE / Bass Out
Choices: Subwoofer, Front, Both*
Selects speaker(s) for outputting low-frequency
components of the LFE (low-frequency effect sound)
channel or other channels. The output status is as follows.
LFE channel signals
Parameter Subwoofer
Front
speakers
Other
speakers
Subwoofer Output Not output Not output
Front Not output Output Not output
Both Output Not output Not output
Low-frequency components of other channel signals
Parameter Subwoofer
Front
speakers
other
speakers
Subwoofer HI |2] |2|
Front Not output |3| |2]
Both |3] |4| |2]
111 Outputs low-frequency components of the channel of speaker,
the size of which is set to “Small”.
12] Outputs low-frequency components when the sizes of speakers
are set to “Large”.
|31 Outputs low-frequency components of the front left and right
channels and the channel of speaker, the size of which is set to
“Small”.
|41 Outputs low-frequency components of the front left and right
channels.
Front Speaker
Choices: Small, Large*
Sets the sizes of front left and right speakers.
Small Select this when small speakers are
connected. Low-frequency components of the
front left and right channels are output from a
subwoofer.
Large Select this when large speakers are
connected.
Note
• If “LFE / Bass Oul" is set to “Front". “Front Speaker” aiitomalically
switches to “Large" even when it is set to “Small".
Center Speaker
Choices: None, Small*. Large
Sets the size of center speaker.
None Select this when no center speaker is
connected. Center channel signals are spread
to front left and right speakers.
Small Select this when a small center speaker is
connected. Low-frequency components of
center channel are output from a subwoofer.
If a subwoofer is not connected they are
output from front speakers.
Large Select this when a large center speaker is
connected.
Surround Speaker
Choices: None, Small*. Large
Sets sizes of left and right surround speakers.
None Select this when no surround speakers are
connected. Surround channel signals are
spread to front left and right speakers.
“Surround Back Speaker” automatically
switches to “None” when this is selected.
Small Select this when small surround speakers are
connected. Low-frequency components of
surround channels are output from a
subwoofer. If a subwoofer is not connected
they are output from front speakers.
Large Select this when large surround speakers are
connected.
• When “None" is selected, the sound field programs aulomatically enter
the Virtual CINEMA DSP mode. '
Surround Back Speaker
Choices: None, Large x 1, Small x 1, Large x 2, Small x 2*
Sets sizes of left and right surround back speakers.
None Select this when no surround back speaker
are connected. Surround back channel signals
are output from the surround L/R speakers
and subwoofer. If the subwoofer is disabled,
they are output from the surround L/R
speakers and front speakers.
Large
X
1 Select this when one large surround back
speaker is connected.
Small X 1 Select this when one small surround back
speaker is connected.
Large X 2 Select this when two large surround back
speakers are connected.
Small
X
2 Select this when two small surround back
speakers are connected.
• When “Surround Back Speaker” is set to “None". “PLIIx Movie".
“PLIIx Music" and “PLIIx Game" of the surround decode mode
(page 27) are not available.
56 En
