Scene File Menu

•C Phase 1 (changes in color bars”“*® on vectorscope)

'=!>

Fig. 5

Phase changes in R-Y axis

direction.

Fig. 6

•C Phase 2 (changes in color bars''*’*^ on vectorscope)

Fig. 7

Phase changes in B-Y axis

direction.

NOTE

Color bars are used in the figures to make the description easier to understand. However, the actual color bars are generated by
a fixed generator so that the bars do not change at all. The only change is in the images shot by the camera.
