Select the desired input signals using the audio input selector
switches.
f—
r-AUDIO IN-1
CHI CH2
MIC ¿Ci PROMT
0«if,gRE*R
J
The sanne sound is input for normal audio and Hi-Fi audio.
When the built-in microphone is used ■ ► FRONT MIC
When an external microphone is used ■ \ REAR MIC
When line audio signals are input ^ REAR LINE
Turn the audio level controls clockwise or counterclockwise and
adjust them so that the audio signal levels indicated on the display’s
level meter are brought to the standard positions.
The audio signal levels can be adjusted when the AUDIO AGC
switch is OFF. If this switch is ON, the signals will be automati­
cally adjusted to more or less the appropriate levels regardless
of the audio level control settings.
Howling may occur if the voiume of the audio monitor speaker is
turned up high. If this occurs, turn the audio monitor level control
and lower the volume to a level at which howling does not occur.
•When the AUDIO AGC switch is at LIMIT, the limiter will be
automatically activated when the input level of the signals is
excessively high. Therefore, first adjust the level with the
switch at OFF and then return the switch to LIMIT just in case
excessively high input signals are supplied.
