MFD Displays
Note: At the time of this publica -
tion, TCAS displays in con -
junction with other display for -
mats has not been certified.
EGPWS INTERFACE
o
Beginning with software 14, a
configuration option available at
the time of installation and certifi-
cation provides an EGPWS ter-
rain display on the MFD.
w
EGPWS SELECTION
Beginning with EFS software 14,
a dedicated Terrain Select push
button determines w hether
Weather or Terrain data is shown
on the MFD.
When EGPWS is manually
selected via the Terrain Select
pushbutton, the terrain data will
be displayed in the currently
selected HSI/ARC format.
When EGPWS is automatically
(pop-up) selected, the display will
change to:
ARC format, 10 NM range
Automatic selection (pop-up) is
initiated by the EGPWS detecting
a terrain Warning or Caution con-
dition and setting a pop-up dis-
crete. Pop-up is monitored only
when the terrain is selected.
Upon deselection of Terrain
mode, weather data will be redis-
played in the current HSI/ARC
format. The previous scan angle
for weather will be restored. If VP
or SS was selected prior to ter-
rain selection, VP or SS display
mode will be restored.
w
EGPWS DISPLAY FORMAT
Terrain display will show 180° of
scan angle and normally contain
the following elements:
* Mode/status annunciation.
* Range annunciation.
w
EGPWS MODE/STATUS
EGPWS mode will be presented
on three lines in the bottom right
(or left, as configured) corner of
the display.
The first line will be a white
TERR annunciation. Lines two
and three each may be a six
character text message annuciat-
ing
the current EGPWS
m o d e / s t a t u s .
TEST - EGPWS processor is
performing system test.
TERR FAIL - EGPWS processor
is no longer communicating
with the EFIS system.
TERR RANGE E XCE ED - A
range greater than 320 nm is
selected.
TERR RANGE FAULT - Indi -
cates a mismatch of the speci -
fied range between the EFIS
CP and the 453 data.
EGPWS PEAKS ELEVATION -
Maximum peaks elevation dis -
played over minimum peaks
elevation.
w
EGPWS RANGE
Range control will be retained by
4.4.16 Issued 8/10 SW 04/05/06/07/08/09/10/11/12/13/14/15/16
Section 4.4mp 9/9/10 3:48 AM Page 4.4.16
