EADI Displays
Two additional features were
added with 09 EFS software to
accomodate the KFC 500 autopi-
lot. Numerical bank limit annunci-
ation and selected heading input
from the flight control computer
(FCC). The numerical bank limit
is annunciated in green as
“BLXX” where XX is the bank
limit in degrees (1 to 30) provided
by the FCC. This annunciation
has priority over “HB” (half bank)
which can be displayed in the
4.2.7 Issued 8/10 SW 04/05/06/07/08/09/10/11/12/13/14/15/16
SFIM CDV ENGAGED MODES
LATERAL VERTICAL COLLECTIVE
BC
CPOS
GSPD
HDG
HOV
LOC
NAV
TST
VORA
AZ
BAZ
ALT
CPOS
GA
GS
GSPD
HOV
IAS
TDWN
TST
TUP
VS
ALT
CHT
CRHT
GA
GS
HHT
TDWN
TST
TUP
VS
SFIM CDV ARMED MODES
LATERAL VERTICAL COLLECTIVE
BC
CPOS
LOC
NAV
OSS
VORA
CPOS
GS
TDWN
CHT
GS
TDWN
same field. Acceptance of select-
ed heading from the FCC allows
the pilot to use the Cyclic Beep
Trim (CBT) switch to move the
heading bug displayed on the
EHSI compass card while the
heading select mode is active.
Beginning with software veresion
14, the KFC 225 autopilot was
added, and REV is annunciated
instead of BC for the KFC 225
o n l y .
w
SFIM CDV AUTOPILOT/
FLIGHT DIRECTOR MODE
A N N U N C I A T I O N
o
When the EFS 40/50 is config-
ured to interface with the SFIM
CDV 155 Autopilot/Flight Direc-
tor, a unique set of armed and
engaged lateral, vertical and col-
lective mode annunciations will
be displayed. Engaged modes
are displayed in green across the
top of the EADI and armed
modes are displayed in white on
the second line from the top on
the EADI.
The following annunciation modi-
fiers are also provided by the
SFIM CDV Autopilot/Flight Direc-
t o r :
• Green Autopilot Coupled Box
around the mode annunciator
• Flashing Yellow Excessive
Deviation Chevron
