Kit components – Waterworks R.W. Atlas Low Profile Concealed Tub Filler With Handshower and Metal Lever Handles User Manual
Page 10
11
W W W.WATERWORKS.COM
10
PRODUCT SUPPORT: 1 (800) 927-2120 (EXT 2)
*FINISH/COLOR MUST BE SPECIFIED WHEN ORDERING
++SUPPLIED AS A PAIR
STYLES: RWTF01, RWTF10
KIT COMPONENTS
KIT COMPONENTS
103471
MOUN TING
HARDWARE
RUBBER WASHER
PLASTIC WASHER
NUT
103727*
DIVERTER TEE
O-RING
TEE
RUBBER WASHER
HOUSING
DIVERTER ROD
103678
CHECK VALVE
