Page 3
HIGHGATE
Volume Control Valve Trim
INSTALLATION GUIDELINES
Page 3 of 3
6.6.2012
These guidelines have been prepared for the professional contractor to aid in the installation of:
HIGHGATE VOLUME CONTROL VALVE TRIM WITH METAL CROSS HANDLE (STYLE# HGVC40) &
PORCELAIN LEVER HANDLE (STYLE# HGVC50)
All dimensions are based on original specification and are subject to change and variation.
Please consult your Design Associate for current specifications.
4
3
1
2
Description
QTY
HGVC40
(CROSS HANDLE)
1
Metal Cross Handle Assembly
1
HGVC50
(LEVER HANDLE)
2
White Porcelain Lever Handle
Assembly
1
COMMON PARTS
3 Escutcheon
1
4 Rubber
Washer
1
