Page 3
HIGHGATE
Thermostatic Control Valve Trim
INSTALLATION GUIDELINES
Page 3 of 3
6.6.2012
These guidelines have been prepared for the professional contractor to aid in the installation of:
HIGHGATE THERMOSTATIC CONTROL VALVE TRIM WITH METAL CROSS HANDLE (STYLE#
HGTH01) & PORCELAIN LEVER HANDLE (STYLE# HGTH10)
All dimensions are based on original specification and are subject to change and variation.
Please consult your Design Associate for current specifications.
1
2
3
4
5
6
7
Description
QTY
HGTH01
(CROSS HANDLE)
1
Metal Cross Handle Assembly
1
HGTH10
(LEVER HANDLE)
2
White Porcelain Lever Handle
Assembly
1
COMMON PARTS
3 Escutcheon
1
4 Rubber
Washer
1
5 Trim
Connector
1
6 Trim
Plate
1
7 Gasket
1
