Installation guidelines – Waterworks Easton Vintage Volume Control Valve Trim with Oak Lever Handles User Manual
Page 3
Easton
®
Wall Valve Trim - Uncovered & Covered
Installation Guidelines
W A T E R W O R K S
®
2
3
4
1
19
10
11
9
8
7
5
17
18
6
14
16
13
12
15
Figure 2
12/03
These guidelines have been prepared for the professional contractor to aid in the installation of:
EASTON
®
WALL VALVE TRIM (UNCOVERED-EASV11,12-K,13-K14-K,15-
K)(COVERED-EASV01,02-K,03-K,04-K,05-K)
All dimensions are based on original specifications and are subject to change and variation.
Please consult your Design Associate for current specifications.
