Easton ® Wall Valve Trim - Uncovered & Covered
12.Thread the threaded sleeve back onto the valve stem (2)
and mark the stem at a point that is flush with the end of
the threaded sleeve.
13.Remove the threaded sleeve and valve stem and then cut
the valve stem 1 /
2
" BEYOND the mark made in step 11.
14.Reinstall the valve stem and then the threaded sleeve and
make sure the stem tip is 1 /
2
" beyond the end of the sleeve
as shown in Figure 2.
15.Attach the handle trim connector and handle assembly to
the threaded sleeve. Do not over-tighten the trim connector
or the handle may bind.
16.Slide the escutcheon back against the nut. Adjust the handle
trim connector to make sure there are no gaps between the
escutcheon (5) and nut (14). If gaps remain, cut the threaded
sleeve and/or the valve stem.
17.Go to step 22.
18.Pull the tile shield (4) off the threaded sleeve (3) and
unthread the sleeve from the valve body.
19.Unthread the valve stem (2) and cut off 5 of the splined
sections so the trim connector assembly (6-10) can be
threaded onto the valve stem.
20.Reinstall the valve stem, thread the handle trim connector
(6-10) onto the valve stem and slide the escutcheon (5)
onto the connector.
21.Thread the handle assembly (14-17) onto the handle trim
connector and then slide the escutcheon back against the
nut (14). Adjust the handle trim connector to make sure
there are no gaps between the escutcheon (5) and nut (14).
If gaps remain, thread the handle trim connector further
onto the valve stem. If the handle does NOT thread on,
loosen the connector to expose more threads on the
connector sleeve (8).
22.Remove the handle assembly (14-17) and escutcheon (5)
and then apply a bead of silicone to the back side of the
escutcheon to create a seal against the wall. Reinstall the
esuctcheon and handle assembly.
23.Install the index (19) using the adhesive pad (18).
➢ If further assistance is required, please contact Product
Support at 1-800-927-2120 (8am-7pm EST).
Installation Guidelines
W A T E R W O R K S ®
These guidelines have been prepared for the professional contractor to aid in the installation of:
EASTON
® WALL VALVE TRIM (UNCOVERED-EASV11,12-K,13-K14-K,15-
K)(COVERED-EASV01,02-K,03-K,04-K,05-K)
All dimensions are based on original specifications and are subject to change and variation.
Please consult your Design Associate for current specifications.
12/03
